Image preview - the first page of the document



>> Download smg2334n documenatation <<

Text preview - extract from the document

                                                                                                     SMG2334N
                                                                                            3.5A, 30V, RDS(ON) 60m
                     Elektronische Bauelemente                                          N-Channel Enhancement MOSFET

                                                          RoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free



 DESCRIPTION                                                                                                              SC-59
           These miniature surface mount MOSFETs utilize a
      high cell density trench process to provide low RDS(on) and                                             A
      to ensure minimal power loss and heat dissipation.                                                          L
                                                                                                              3
                                                                                                                                                              3

                                                                                                          Top View            C B
                                                                                                                                             1
 FEATURES                                                                                             1               2

                                                                                                 K            E                                      2

            Low RDS(on) provides higher efficiency and
            extends battery life.                                                                                              D
            Low thermal impedance copper leadframe                                                                                    H                           J
                                                                                                 F                        G
            SC-59 saves board space.
            Fast switching speed.
            High performance trench technology.                                                       REF.
                                                                                                                    Millimeter
                                                                                                                                      REF.
                                                                                                                                                  Millimeter
                                                                                                                   Min.   Max.                   Min.   Max.
                                                                                                          A        2.70    3.10        G          0.10 REF.
                                                                                                          B        2.25    3.00        H          0.40 REF.
                                                                                                          C        1.30    1.70        J         0.10   0.20
 APPLICATION                                                                                              D        1.00    1.40        K         0.45   0.55
           DC-DC converters and power management in                                                       E        1.70    2.30        L         0.85   1.15
                                                                                                          F        0.35    0.50
     portable and battery-powered products such as
     computers, printers, PCMCIA cards, cellular and

     cordless telephones.                                                                                                           Drain




 PACKAGE INFORMATION                                                                                  Gate

             Package                MPQ              LeaderSize
               SC-59                 3K                  7' inch

                                                                                                                                Source



 MAXIMUM RATINGS (TA = 25
