Image preview - the first page of the document



>> Download sms318 documenatation <<

Text preview - extract from the document

                                                                                                          SMS318
                                                                                        220mA, 50V, RDS(ON) 3.5
                     Elektronische Bauelemente                                      N-Channel Enhancement MOSFET

                                                      RoHS Compliant Product
                                            A suffix of "-C" specifies halogen & lead-free



 FEATURES                                                                                                      SOT-23
         Low On-Resistance
                                                                                                      A
         Low Gate Threshold Voltage                                                                       L
         Low Input Capacitance                                                                        3
                                                                                                                                                  3

         Fast Switching Speed                                                                    Top View              C B
         Low Input/Output Leakage                                                                                                   1
                                                                                             1                 2

                                                                                        K          E                                        2


 MECHANICAL DATA
         Case: SOT-23                                                                                                    D
         Case Material: Molded Plastic.                                                 F                          G         H                         J
         UL Flammability Classification Rating 94V-0
         Moisture Sensitivity: Level 1 per J-STD-020C                                            REF.
                                                                                                               Millimeter
                                                                                                                             REF.
                                                                                                                                          Millimeter
                                                                                                              Min.   Max.               Min.    Max.
         Terminals: Solderable per MIL-STD-202, Method 208                                        A           2.70    3.04    G           -     0.18
         Lead Free Plating(Matte Tin Finish Annealed over                                         B           2.10    2.80    H         0.40    0.60
                                                                                                  C           1.20    1.60    J         0.08    0.20
         Alloy 42 leadframe)                                                                      D           0.89    1.40    K            0.6 REF.
         Terminal Connections: See Diagram                                                        E           1.78    2.04    L         0.85    1.15
                                                                                                  F           0.30    0.50
         Weight: 0.008 grams (approximate)

 MARKING
            Product         Marking Code

           SMS318            H03 / SS


 PACKAGE INFORMATION
             Package               MPQ            Leader Size
              SOT-23                3K                7' inch




   ABSOLUTE MAXIMUM RATINGS (TA=25
