Image preview - the first page of the document
>> Download sdf920ne documenatation <<
Text preview - extract from the document
SDF920NE
11A, 20V, RDS(ON) 22 m
Elektronische Bauelemente Dual N-Ch Enhancement Mode Power MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
DESCRIPTION
DFN2x5
These miniature surface mount MOSFETs
utilize a high cell density trench process to provide low
RDS(on) and to ensure minimal power loss and heat
dissipation. Typical applications are DC-DC
converters and power management in portable and
battery-powered products such as computers,. E
C
printers, PCMCIA cards, cellular and cordless
B
telephones H
D
G
FEATURES
Low RDS(on) provides higher efficiency and extends
F
battery life.
A
Low thermal impedance copper leadframe DFN2x5
saves board space
Fast switching speed N L
High performance trench technology O
PACKAGE INFORMATION I
J
Package MPQ Leader Size
DFN2x5 5K 13' inch
K
M
Millimeter Millimeter
REF. REF.
Min. Max. Min. Max.
A 0.70 0.80 I 2.00 BSC
B 0.00 0.06 J 1.30 1.55
C 0.10 0.20 K 2.60 2.86
