Image preview - the first page of the document



>> Download sgm0410 documenatation <<

Text preview - extract from the document

                                                                                                           SGM0410
                                                                                           3.5A , 100V , RDS(ON) 170 m
                     Elektronische Bauelemente                                     N-Channel Enhancement Mode Power MOSFET

                                                                RoHS Compliant Product
                                                      A suffix of "-C" specifies halogen & lead-free



 DESCRIPTION                                                                                                                   SOT-89
        The SGM0410 provide the designer with the best
                                                                                                                   A
   combination of fast switching, ruggedized device design, low
   on-resistance and cost-effectiveness. The SOT-89 package                                                                                                    4
   is universally preferred for all commercial-industrial surface                                            Top View       CB
   mount applications and suited for low voltage applications                                                                          1
   such as DC/DC converters.                                                                           K               L                    2
                                                                                                                                                  3

                                                                                                                   E

                                                                                                                                D
 FEATURES
                                                                                                       F                   G           H                           J
         Lower Gate Charge
         Simple Drive Requirement
         Fast Switching Characteristic                                                                      REF.         Millimeter
                                                                                                                       Min.     Max.
                                                                                                                                           REF.          Millimeter
                                                                                                                                                       Min.     Max.
                                                                                                             A         4.40     4.60        G            -        -
                                                                                                             B         4.05     4.25        H          0.89     1.20
                                                                                                             C         2.40     2.60        J          0.35     0.41
 MARKING                                                                                                     D         1.40     1.60        K          0.70     0.80
                                                                                                             E           3.00 REF.          L            1.50 REF.
        0410                                                                                                 F         0.40     0.52
                             = Date code
                                                                                                                                       D

 PACKAGE INFORMATION
             Package                   MPQ                Leader Size
                                                                                                                       G
              SOT-89                       1K                7 inch

                                                                                                                                       S




 ABSOLUTE MAXIMUM RATINGS (TA=25
