Image preview - the first page of the document
>> Download sgm0410s documenatation <<Text preview - extract from the document SGM0410S
2.2A , 100V , RDS(ON) 310 m
Elektronische Bauelemente N-Channel Enhancement Mode Power MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
DESCRIPTION SOT-89
The SGM0410S provide the designer with the best A
combination of fast switching, ruggedized device design, low
on-resistance and cost-effectiveness. The SOT-89 package
is universally preferred for all commercial-industrial surface
Top View CB 4
mount applications and suited for low voltage applications
1
such as DC/DC converters. K L 2
3
E
FEATURES D
Lower Gate Charge F G H J
Simple Drive Requirement
Fast Switching Characteristic Millimeter Millimeter
REF. REF.
Min. Max. Min. Max.
A 4.40 4.60 G - -
B 4.05 4.25 H 0.89 1.20
MARKING C 2.40 2.60 J 0.35 0.41
D 1.40 1.60 K 0.70 0.80
E 3.00 REF. L 1.50 REF.
0410S F 0.40 0.52
= Date code
D
24
PACKAGE INFORMATION
Package MPQ Leader Size
1
SOT-89 1K 7 inch G
3
S
ABSOLUTE MAXIMUM RATINGS (TA=25
