Image preview - the first page of the document



>> Download sgm3055 documenatation <<

Text preview - extract from the document

                                                                                                         SGM3055
                                                                                            5.8A , 30V , RDS(ON) 28 m
                     Elektronische Bauelemente                                    N-Channel Enhancement Mode Power MOSFET

                                                              RoHS Compliant Product
                                                    A suffix of "-C" specifies halogen & lead-free



 DESCRIPTION                                                                                                                    SOT-89
        The GM3055 provide the designer with the best
                                                                                                                A
   combination of fast switching, ruggedized device design, low
   on-resistance and cost-effectiveness. The SOT-89 package                                                                                                  4
   is universally preferred for all commercial-industrial surface                                          Top View         CB
   mount applications and suited for low voltage applications                                                                        1
   such as DC/DC converters.                                                                         K              L                     2
                                                                                                                                                3

                                                                                                                E

                                                                                                                                D
 FEATURES
                                                                                                     F                      G        H                           J
         Fast Switching
         Dynamic dv/dt Rating
         Repetitive Avalanche Rated                                                                      REF.          Millimeter
                                                                                                                     Min.     Max.
                                                                                                                                         REF.          Millimeter
                                                                                                                                                     Min.     Max.
         Simple Drive Requirement                                                                          A         4.40     4.60        G            -        -
                                                                                                           B         4.05     4.25        H          0.89     1.20
                                                                                                           C         2.40     2.60        J          0.35     0.41
                                                                                                           D         1.40     1.60        K          0.70     0.80
 MARKING                                                                                                   E           3.00 REF.          L            1.50 REF.
                                                                                                           F         0.40     0.52
        3055
                             = Date code                                                                                             D


 PACKAGE INFORMATION

             Package                  MPQ              Leader Size                                                      G

              SOT-89                   1K                   7 inch
                                                                                                                                     S




 ABSOLUTE MAXIMUM RATINGS (TA=25
