Image preview - the first page of the document
>> Download sid10n30-600i documenatation <<Text preview - extract from the document SID10N30-600I
7.5A, 300V, RDS(ON) 600 m
Elektronische Bauelemente N-Channel Enhancement MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
DESCRIPTION TO-251P
The miniature surface mount MOSFETs utilize a high
cell density trench process to provide Low RDS(on) and
to ensure minimal power loss and heat dissipation.
FEATURES
Low RDS(on) provides higher efficiency and extends
battery life.
Low thermal impedance copper leadframe
A
DPAK saves board space B C
D
Fast switching speed.
High performance trench technology.
GE
APPLICATION K
DC-DC converters, power management in portable and F
H
battery-powered products such as computers, printers,
PCMCIA cards, cellular and cordless telephones.
M J P
Millimeter Millimeter
REF. REF.
Min. Max. Min. Max.
A 6.40 6.80 G 6.00 6.30
B 5.20 5.50 H 0.90 1.50
C 2.20 2.40 J 2.30
D 0.40 0.60 K 0.60 0.90
E 6.80 7.20 M 0.70 1.20
F 4.00 P 0.40 0.60
ABSOLUTE MAXIMUM RATINGS (TA=25
