Image preview - the first page of the document



>> Download ssu50n10 documenatation <<

Text preview - extract from the document

                                                                                                      SSU50N10
                                                                                             54A , 100V , RDS(ON) 22m
                     Elektronische Bauelemente                                        N-Ch Enhancement Mode Power MOSFET

                                                            RoHS Compliant Product
                                                      A suffix of "-C" specifies halogen free


 DESCRIPTION                                                                                                             TO-263
       The SSU50N10 is the highest performance trench
   N-ch MOSFETs with extreme high cell density , which provide
  excellent RDS(ON) and gate charge for most of the synchronous
  buck converter applications .

 FEATURES
        Advanced high cell density Trench technology
        Super Low Gate Charge
        Excellent CdV/dt effect decline
        100% EAS and 100% Rg Guaranteed
        Green Device Available


 MARKING
        50N10
                        Date Code
                                                                                                2
                                                                                            Drain

                                                                                                                   Millimeter                     Millimeter
 PACKAGE INFORMATION                                                          1                         REF.
                                                                                                                 Min.     Max.
                                                                                                                                     REF.
                                                                                                                                                Min.     Max.
                                                                              Gate                          A    4.40     4.80        c2        1.17     1.45
            Package                   MPQ            Leader Size                                            b    0.76     1.00        b2        1.1      1.47
                                                                                                            L4   0.00     0.30        D         8.5       9.0
                                                                                                             c   0.36      0.5         e          2.54 REF
             TO-263                   0.8K              13 inch                                             L3     1.50 REF            L        14.6     15.8
                                                                                                3           L1   2.29     2.79                   0
