Image preview - the first page of the document



>> Download ssd04n65 documenatation <<

Text preview - extract from the document

                                                                                                     SSD04N65
                                                                                          4A , 650V , RDS(ON) 2.6
                     Elektronische Bauelemente                                    N-Ch Enhancement Mode Power MOSFET

                                                        RoHS Compliant Product
                                                  A suffix of "-C" specifies halogen free



 DESCRIPTION                                                                                                         TO-252(D-Pack)
           The SSD04N65 is the highest performance trench
  N-ch MOSFETs with extreme high cell density , which provide
  excellent RDS(on) and gate charge for most of the synchronous
  buck converter applications .


 FEATURES                                                                                                              A
                                                                                                                       B                               C
        Advanced high cell density Trench technology                                                                                                   D

        Super Low Gate Charge
        Excellent CdV/dt effect decline                                                                                              GE
        100% EAS Guaranteed
        Green Device Available
                                                                                                                           K         HF                N
                                                                                                                                                       O
                                                                                                                                                       P
 MARKING                                                                                                     M             J

                                                                                            Drain
                                                                                                             REF.
                                                                                                                       Millimeter    REF.
                                                                                                                                              Millimeter
        4N65                                                                                                         Min.    Max.            Min.   Max.
                            Date Code

                                                                                                                 A
                                                                                                                 B
                                                                                                                     6.35
                                                                                                                     5.20
                                                                                                                              6.80
                                                                                                                              5.50
                                                                                                                                      J
                                                                                                                                      K
                                                                                                                                              2.30 REF.
                                                                                                                                             0.64   0.90
                                                                                                                 C   2.15     2.40    M      0.50    1.1
                                                                            Gate
                                                                                                                 D   0.45     0.58    N      0.9    1.65
                                                                                                                 E    6.8      7.5    O        0    0.15
                                                                                                                 F   2.40      3.0    P      0.43   0.58
 PACKAGE INFORMATION                                                                                             G   5.40     6.25
                                                                                                                 H   0.64     1.20
            Package                     MPQ       Leader Size                               Source
             TO-252                      2.5K       13 inch




 ABSOLUTE MAXIMUM RATINGS (TA=25
