Image preview - the first page of the document
>> Download ssd20n10-130d documenatation <<Text preview - extract from the document SSD20N10-130D
17A , 100V , RDS(ON) 130m
Elektronische Bauelemente N-Ch Enhancement Mode Power MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen free
DESCRIPTION TO-252(D-Pack)
These miniature surface mount MOSFET utilize a
high cell density trench process to provide low RDS(on)
and to ensure minimal power loss and heat dissipation.
FEATURES
Low RDS(on) provides higher efficiency and extends
battery life A
B C
Low thermal impedance copper leadframe TO-252 D
saves board space
Fast switching speed
GE
High performance trench technology
K HF N
APPLICATION O
P
DC-DC converters and power management in portable and M J
battery-powered products such as computers, printers, Millimeter Millimeter
REF. REF.
Min. Max. Min. Max.
PCMCIA cards, cellular and cordless telephones. A 6.35 6.80 J 2.30 REF.
B 5.20 5.50 K 0.64 0.90
C 2.15 2.40 M 0.50 1.1
D 0.45 0.58 N 0.9 1.65
E 6.8 7.5 O 0 0.15
PACKAGE INFORMATION F 2.40 3.0 P 0.43 0.58
G 5.40 6.25
H 0.64 1.20
Package MPQ Leader Size
TO-252 2.5K 13 inch 2
Drain
1
Gate
3
Source
ABSOLUTE MAXIMUM RATINGS (TA=25
