Image preview - the first page of the document



>> Download ssd20n10-250d documenatation <<

Text preview - extract from the document

                                                                                           SSD20N10-250D
                                                                                 N-Ch Enhancement Mode Power MOSFET
                     Elektronische Bauelemente                                          11A, 100V, RDS(ON) 280m

                                                       RoHS Compliant Product
                                                 A suffix of "-C" specifies halogen free
 DESCRIPTION
     These miniature surface mount MOSFETs utilize a high cell density trench                                      TO-252(D-Pack)
     process to provide Low RDS(on) and to ensure minimal power loss and heat dissipation.
     Typical applications are DC-DC converters and power management in portable
     and battery-powered products such as computers, printers, PCMCIA cards, cellular
     and cordless telephones.


 FEATURES
           Low RDS(on) provides higher efficiency and extends battery life.
           Low thermal impedance copper leadframe DPAK saves board space.
           Fast switching speed.                                                                                     A
                                                                                                                     B                                 C
           High performance trench technology.                                                                                                         D



 PRODUCT SUMMARY
                                                                                                                                   GE
                        PRODUCT SUMMARY
         VDS(V)            RDS(on) m(            ID(A)
                          280@VGS= 10V             11                                                                    K         HF                  N
           100
                         355@VGS= 4.5V            10                                                                                                   O
                                                                                                                                                       P
                                                                                       Drain              M              J



                                                                                                                     Millimeter               Millimeter
                                                                         Gate                               REF.
                                                                                                                   Min.    Max.
                                                                                                                                    REF.
                                                                                                                                            Min.    Max.
                                                                                                              A     6.4      6.8     J        2.30 REF.
                                                                                                              B    5.20     5.50     K      0.70    0.90
                                                                                                              C    2.20     2.40     M      0.50     1.1
                                                                                                              D    0.45     0.58     N       0.9     1.6
                                                                                                              E     6.8      7.3     O        0     0.15
                                                                                      Source                  F    2.40      3.0     P      0.43    0.58
                                                                                                              G    5.40      6.2
                                                                                                              H     0.8     1.20

 ABSOLUTE MAXIMUM RATINGS (TA = 25
