Image preview - the first page of the document
ssd20p06-135d


>> Download ssd20p06-135d documenatation <<

Text preview - extract from the document
                                                                                                  SSD20P06-135D
                                                                                    P-Ch Enhancement Mode Power MOSFET
                     Elektronische Bauelemente                                             16A, -60V, RDS(ON) 135m

                                                          RoHS Compliant Product
                                                    A suffix of "-C" specifies halogen free
 DESCRIPTION
     These miniature surface mount MOSFETs utilize a high cell density trench
     process to provide Low RDS(on) and to ensure minimal power loss and heat                                              TO-252(D-Pack)
     dissipation. Typical applications are DC-DC converters and power management
     in portable and battery-powered products such as computers, printers,
     PCMCIA cards, cellular and cordless telephones.


 FEATURES
           Low RDS(on) provides higher efficiency and extends battery life.
           Low thermal impedance copper leadframe DPAK saves board space.
           Fast switching speed.                                                                                               A
                                                                                                                               B                        C
                                                                                                                                                        D
           High performance trench technology..

                                                                                                                                           GE
 PRODUCT SUMMARY
                        PRODUCT SUMMARY                                                                                            K       HF           N
         VDS(V)           RDS(on) m(                ID(A)                                                                                               O
                                                                                                                                                        P
                                                                                                                       M           J
                         135@VGS= -10V               16                                   Drain
            -60
                         190@VGS= -4.5V              14
                                                                                                                             Millimeter             Millimeter
                                                                                                                  REF.                      REF.
                                                                            Gate                                           Min.    Max.            Min.   Max.
                                                                                                                   A        6.4      6.8     J      2.30 REF.
                                                                                                                   B       5.20     5.50     K     0.70   0.90
                                                                                                                   C       2.20     2.40     M     0.50    1.1
                                                                                                                   D       0.45     0.58     N     0.9     1.6
                                                                                                                   E        6.8      7.3     O       0    0.15
                                                                                         Source                    F       2.40      3.0     P     0.43   0.58
                                                                                                                   G       5.40      6.2
                                                                                                                   H        0.8     1.20




 ABSOLUTE MAXIMUM RATINGS (TA = 25
