Image preview - the first page of the document



>> Download ssd2504 documenatation <<

Text preview - extract from the document

                                                                                              SSD2504
                                                                                 N-Ch Enhancement Mode Power MOSFET
                     Elektronische Bauelemente                                          5.0A, 100V, RDS(ON) 0.22

                                                       RoHS Compliant Product
                                                 A suffix of "-C" specifies halogen free
 DESCRIPTION
     The SSD2504 provide the designer with the best combination of fast switching.
     The TO-252 package is universally preferred for all commercial-industrial                                  TO-252(D-Pack)
     surface mount applications. The device is suited for charger, industrial and
     consumer environment.


 FEATURES
           Low On-resistance
           Fast Switching Speed
           Low-voltage drive (4V)
                                                                                                                      A
           Wide SOA (safe operating area)                                                                             B                      C
                                                                                                                                             D

           Easily designed drive circuits
           Easy to parallel                                                                                                     GE



                                                                                                                          K     HF           N

 MARKING                                                                                                        M         J
                                                                                                                                             O
                                                                                                                                             P




                                                                                 Drain
                                                                                                                  Millimeter                Millimeter
                                                                                                         REF.                    REF.
                                                                                                                Min.    Max.              Min.    Max.
                                                                                                          A      6.4      6.8        J      2.30 REF.
                                                                                                          B     5.20     5.50        K    0.70    0.90
                                                                 Gate                                     C     2.20     2.40        M    0.50     1.1
                                                                                                          D     0.45     0.58        N     0.9     1.6
                                                                                                          E      6.8      7.3        O      0     0.15
                                                                                                          F     2.40      3.0        P    0.43    0.58
                                                                                                          G     5.40      6.2
                                                                              Source                      H      0.8     1.20




 ABSOLUTE MAXIMUM RATINGS (TA = 25
