Image preview - the first page of the document
>> Download ssd30n06-39d documenatation <<
Text preview - extract from the document
SSD30N06-39D
N-Ch Enhancement Mode Power MOSFET
Elektronische Bauelemente 30A, 60V, RDS(ON) 38 m
RoHS Compliant Product
A suffix of "-C" specifies halogen free
TO-252(D-Pack)
DESCRIPTION
These miniature surface mount MOSFETs utilize a high cell density
trench process to provide low RDS(on) and to ensure minimal power loss and
heat dissipation. Typical applications are DC-DC converters and power
management in portable and battery-powered products such as computers,
printers, PCMCIA cards, cellular and cordless telephones.
FEATURES
Low RDS(on) provides higher efficiency and extends battery life A
B C
Low thermal impedance copper leadframce DPAK saves D
board space
Fast switching speed
High performance trench technology GE
PRODUCT SUMMARY
K HF N
PRODUCT SUMMARY O
P
VDS(V) RDS(on) m( ID(A) M J
38 @VGS= 10V 30 Drain
60
50 @VGS= 4.5V 26
Gate REF.
Millimeter
REF.
Millimeter
Min. Max. Min. Max.
A 6.4 6.8 J 2.30 REF.
B 5.20 5.50 K 0.70 0.90
C 2.20 2.40 M 0.50 1.1
D 0.45 0.58 N 0.9 1.6
E 6.8 7.3 O 0 0.15
Source F 2.40 3.0 P 0.43 0.58
G 5.40 6.2
H 0.8 1.20
ABSOLUTE MAXIMUM RATINGS (TA = 25◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
