Image preview - the first page of the document



>> Download ssd30n10-70d documenatation <<

Text preview - extract from the document

                                                                                               SSD30N10-70D
                                                                                 N-Ch Enhancement Mode Power MOSFET
                     Elektronische Bauelemente                                          21A, 100V, RDS(ON) 78 m

                                                       RoHS Compliant Product
                                                 A suffix of "-C" specifies halogen free
                                                                                                                     TO-252(D-Pack)
 KEY FEATURES
           Low RDS(on) trench technology
           Low thermal impedance
           Fast switching speed


 Typical Applications
           PoE Power Sourcing Equipment
           PoE Powered Devices                                                                                          A
           Telecom DC/DC converters                                                                                     B                                C
                                                                                                                                                         D
           While LED boost converters

 PRODUCT SUMMARY                                                                                                                     GE

                            PRODUCT SUMMARY
          VDS(V)              RDS(on) m(             ID(A)                                                                  K        HF                  N
                                                                                                                                                         O
                             78 @VGS= 10V              21                                                                                                P
            100                                                                                               M             J
                             92 @VGS= 4.5V             19
                                                                                           Drain

                                                                                                                       Millimeter              Millimeter
                                                                                                              REF.                    REF.
                                                                                                                     Min.    Max.            Min.    Max.
                                                                                                               A      6.4      6.8     J       2.30 REF.
                                                                          Gate                                 B     5.20     5.50     K     0.70    0.90
                                                                                                               C     2.20     2.40     M     0.50     1.1
                                                                                                               D     0.45     0.58     N      0.9     1.6
                                                                                                               E      6.8      7.3     O       0     0.15
                                                                                                               F
                                                                                                               G
                                                                                                                     2.40
                                                                                                                     5.40
                                                                                                                               3.0
                                                                                                                               6.2
                                                                                                                                       P     0.43    0.58

                                                                                       Source                  H      0.8     1.20



 ABSOLUTE MAXIMUM RATINGS (TA = 25
