Image preview - the first page of the document



>> Download ssd40n04-20d documenatation <<

Text preview - extract from the document

                                                                                              SSD40N04-20D
                                                                                    N-Ch Enhancement Mode Power MOSFET
                     Elektronische Bauelemente                                              39A, 40V, RDS(ON) 22m

                                                          RoHS Compliant Product
                                                    A suffix of "-C" specifies halogen free                           TO-252(D-Pack)
 DESCRIPTION
     These miniature surface mount MOSFETs utilize a high cell density process.
     Low RDS(on) assures minimal power loss and conserves energy, making this
     device ideal for use in power management circuitry. Typical applications are
     PWMDC-DC converters, power management in portable and battery-powered
     products such as computers, printers, battery charger, telecommunication
     power system, and telephones power system.
                                                                                                                          A
                                                                                                                          B                        C
                                                                                                                                                   D
 FEATURES
           Low RDS(on) provides higher efficiency and extends battery life.
                                                                                                                                      GE
           Miniature TO-252 surface mount package saves board space.
           High power and current handling capability.
           Low side high current DC-DC Converter applications.                                                                K       HF           N
                                                                                                                                                   O
                                                                                                                                                   P
                                                                                                                  M           J


 PRODUCT SUMMARY                                                                                             REF.
                                                                                                                        Millimeter
                                                                                                                                       REF.
                                                                                                                                               Millimeter
                                                                                                                      Min.    Max.            Min.   Max.
                        PRODUCT SUMMARY                                                                       A        6.4      6.8     J      2.30 REF.
                                                                                                              B       5.20     5.50     K     0.70   0.90
         VDS(V)            RDS(on) m(               ID(A)                                                     C       2.20     2.40     M     0.50    1.1
                                                                                                              D       0.45     0.58     N     0.9     1.6
                          22@VGS= 10V                39                                                       E        6.8      7.3     O       0    0.15
            40                                                                                                F       2.40      3.0     P     0.43   0.58
                          27@VGS= 4.5V               36                                                       G       5.40      6.2
                                                                                                              H        0.8     1.20



                                                                                                                                           Drain



                                                                                                                      Gate




                                                                                                                                       Source

 ABSOLUTE MAXIMUM RATINGS (TA = 25
