P-Ch Enhancement Mode Power MOSFET
Elektronische Bauelemente -36A, -40V, RDS(ON) 30m
RoHS Compliant Product
A suffix of "-C" specifies halogen free
DESCRIPTION
These miniature surface mount MOSFETs utilize high cell density process.
Low RDS(on) assures minimal power loss and conserves energy, making this TO-252(D-Pack)
device ideal for use in power management circuitry. Typical applications
are PWMDC-DC converters, power management in portable and battery-powered
products such as computers, printers, battery charger, telecommunication
power system, and telephones power system.
FEATURES
Low RDS(on) provides higher efficiency and extends battery life.
Miniature TO-252 surface mount package saves board space.
High power and current handling capability. A
B C
D
Extended VGS range (
