Image preview - the first page of the document



>> Download ssd50n06-15d documenatation <<

Text preview - extract from the document

                                                                                             SSD50N06-15D
                                                                               N-Ch Enhancement Mode Power MOSFET
                     Elektronische Bauelemente                                         51A, 60V, RDS(ON) 13 m

                                                      RoHS Compliant Product
                                            A suffix of "-C" specifies halogen & lead-free
                                                                                                                TO-252(D-Pack)
 DESCRIPTION
        These miniature surface mount MOSFETs utilize high cell density
 process. Low RDS(on) assures minimal power loss and conserves energy,
 making this device ideal for use in power management circuitry. Typical
 applications are PWM DC-DC converters, power management in portable
 and battery-powered products such as computers, printers, battery charger,
 telecommunication power system, and telephones power system.
                                                                                                                   A
                                                                                                                   B                               C
                                                                                                                                                   D
 FEATURES
           Low RDS(on) Provides Higher Efficiency and Extends Battery Life
           Miniature TO-252 Surface Mount Package Saves Board Space
                                                                                                                                 GE
           High power and current handling capability
           Low side high current DC-DC Converter applications
                                                                                                                       K         HF                N
                                                                                                                                                   O
 PRODUCT SUMMARY                                                                                                                                   P
                                                                                                        M              J
                            PRODUCT SUMMARY
          VDS(V)               RDS(on) m(           ID(A)                                                          Millimeter               Millimeter
                                                                                                         REF.                     REF.
                                                                                                                 Min.    Max.              Min.   Max.
                              13 @VGS= 10V           51                                                     A     6.4      6.8     J        2.30 REF.
             60                                                                                             B    5.20     5.50     K       0.70   0.90
                              18 @VGS= 4.5V          44                                                     C    2.20     2.40     M       0.50    1.1
                                                                                                            D    0.45     0.58     N       0.9     1.6
                                                                                                            E     6.8      7.3     O         0    0.15
                                                                                                            F    2.40      3.0     P       0.43   0.58
                                                                                                            G    5.40      6.2
                                                                                                            H     0.8     1.20




                                                                                                                                  Drain



                                                                                                                Gate




                                                                                                                                 Source
