Image preview - the first page of the document
>> Download ssd70n03-04d documenatation <<
Text preview - extract from the document
SSD70N03-04D
75A, 30V, RDS(ON) 6 m
Elektronische Bauelemente N-Ch Enhancement Mode Power MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen free
DESCRIPTION TO-252(D-Pack)
These miniature surface mount MOSFETs utilize high
cell density process. Low RDS(on) assures minimal power
loss and conserves energy, making this device ideal for
use in power management circuitry. Typical applications
are PWMDC-DC converters, power management in
portable and battery-powered products such as computers,
printers, battery charger, telecommunication power system,
and telephones power system. A
B C
D
FEATURES GE
Low RDS(on) provides higher efficiency and extends
battery life. K HF N
Miniature TO-252 surface mount package saves O
P
board space. M J
High power and current handling capability. Millimeter Millimeter
Low side high current DC-DC converter applications. REF.
Min. Max.
REF.
Min. Max.
A 6.4 6.8 J 2.30 REF.
B 5.20 5.50 K 0.70 0.90
C 2.20 2.40 M 0.50 1.1
D 0.45 0.58 N 0.9 1.6
PACKAGE INFORMATION E 6.8 7.3 O 0 0.15
F 2.40 3.0 P 0.43 0.58
G 5.40 6.2
Package MPQ LeaderSize H 0.8 1.20
TO-252 2.5K 13' inch
Drain
Gate
Source
