Image preview - the first page of the document



>> Download ssd70n04-06d documenatation <<

Text preview - extract from the document

                                                                                             SSD70N04-06D
                                                                                           75A, 40V, RDS(ON) 6 m
                     Elektronische Bauelemente                                     N-Ch Enhancement Mode Power MOSFET

                                                         RoHS Compliant Product
                                                   A suffix of "-C" specifies halogen free



 DESCRIPTION                                                                                                         TO-252(D-Pack)
           These miniature surface mount MOSFETs utilize high
     cell density process. Low RDS(on) assures minimal power
     loss and conserves energy, making this device ideal for
     use in power management circuitry. Typical applications
     are PWMDC-DC converters, power management in
     portable and battery-powered products such as computers,
     printers, battery charger, telecommunication power system,
     and telephones power system.                                                                                       A
                                                                                                                        B                         C
                                                                                                                                                  D



 FEATURES                                                                                                                         GE
           Low RDS(on) provides higher efficiency and extends
           battery life.                                                                                                    K     HF              N
           Miniature TO-252 surface mount package saves                                                                                           O
                                                                                                                                                  P
           board space.                                                                                          M          J

           High power and current handling capability.                                                             Millimeter              Millimeter
           Low side high current DC-DC converter applications.                                            REF.
                                                                                                                 Min.    Max.
                                                                                                                                  REF.
                                                                                                                                          Min.   Max.
                                                                                                           A      6.4      6.8     J       2.30 REF.
                                                                                                           B     5.20     5.50     K      0.70   0.90
                                                                                                           C     2.20     2.40     M      0.50    1.1
                                                                                                           D     0.45     0.58     N      0.9     1.6
 PACKAGE INFORMATION                                                                                       E      6.8      7.3     O        0    0.15
                                                                                                           F     2.40      3.0     P      0.43   0.58
                                                                                                           G     5.40      6.2
            Package                MPQ            LeaderSize                                               H      0.8     1.20

             TO-252                2.5K              13' inch
                                                                                                                                 Drain



                                                                                                               Gate




                                                                                                                                 Source


 ABSOLUTE MAXIMUM RATINGS (TA = 25
