Image preview - the first page of the document
>> Download ssd95n03 documenatation <<
Text preview - extract from the document
SSD95N03
96A , 30V , RDS(ON) 4m
Elektronische Bauelemente N-Ch Enhancement Mode Power MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen free
DESCRIPTION TO-252(D-Pack)
The SSD95N03 is the highest performance trench
N-ch MOSFETs with extreme high cell density , which provide
excellent RDS(ON) and gate charge for most of the synchronous
buck converter applications .
FEATURES A
B C
D
Advanced high cell density Trench technology
Super Low Gate Charge
Excellent CdV/dt effect decline GE
100% EAS Guaranteed
Green Device Available
K HF N
O
P
M J
MARKING
Millimeter Millimeter
REF. REF.
95N03 Min. Max. Min. Max.
Date Code A 6.35 6.80 J 2.30 REF.
B 5.20 5.50 K 0.64 0.90
C 2.15 2.40 M 0.50 1.1
D 0.45 0.58 N 0.9 1.65
E 6.8 7.5 O 0 0.15
F 2.40 3.0 P 0.43 0.58
PACKAGE INFORMATION G
H
5.40
0.64
6.25
1.20
Package MPQ Leader Size 2
Drain
TO-252 2.5K 13 inch
1
Gate
3
Source
ABSOLUTE MAXIMUM RATINGS (TA=25◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
