Image preview - the first page of the document



>> Download ssdf9504 documenatation <<

Text preview - extract from the document

                                                                                                              SSDF9504
                                                                                                 23A, 40V, RDS(ON) 26m
                                                                                                -20A, -40V, RDS(ON) 40m
                     Elektronische Bauelemente                                      N And P-Channel Enhancement Mode Power MOSFET

                                                                  RoHS Compliant Product
                                                        A suffix of "-C" specifies halogen & lead-free


 DESCRIPTION                                                                                                                 TO-252-4L
       The SSDF9504 provide the designer with best combination
 of fast switching, low on-resistance and cost effectiveness.
       The G4J9504 meet the RoHS and Green Product requirement ,
 100% EAS guaranteed with full function reliability approved.

 FEATURES
        Low Gate Charge
        Low On-resistance

 MARKING CODE

        9504
                            = Date Code



 PACKAGE INFORMATION                                                                                                       Millimeter                   Millimeter
                                                                                                              REF.                        REF.
                                                                                                                          Min.    Max.                Min.     Max.
             Package                      MPQ              Leader Size                                         A          6.4      6.8      F         0.4       0.6
                                                                                                               B          9.4     10.2      G         2.2       2.4
                                                                                                               C          5.4      5.8      H         0.45     0.55
            TO-252-4L                     2.5K                  13 inch                                        D          2.4      3.0      I         1.4       1.8
                                                                                                               E           1.27 REF.        J         0.8       1.2




 ABSOLUTE MAXIMUM RATINGS (TA=25
