Image preview - the first page of the document



>> Download sse90n06-10p documenatation <<

Text preview - extract from the document

                                                                                                   SSE90N06-10P
                                                                                         90A , 60V , RDS(ON) 9.9 m
                     Elektronische Bauelemente                                     N-Channel Enhancement Mode MOSFET

                                                         RoHS Compliant Product
                                             A suffix of "-C" specifies halogen and lead-free



 DESCRIPTION                                                                                                                  TO-220P
      These miniature surface mount MOSFETs utilize a                                                                 D
  High Cell Density trench process to provide low RDS(on)
                                                                                                                      C
  and to ensure minimal power loss and heat dissipation.
                                                                                                                      B                    R
                                                                                                                                                               T
                                                                                                                      A
                                                                                                           E
 FEATURES                                                                                                                                                       S

        Low RDS(on) Provides Higher Efficiency and                                                 G
        Extends Battery Life.
                                                                                                                                   F         I
        Low Thermal impedance copper leadframe                                                         H
        TO-220P saves board space.                                                                             J                 K
        Fast Switch speed.                                                                                                     L
        High performance trench technology.                                                                                                                         U
                                                                                                           X                     M
                                                                                                                                             P
                                                                                                                                 N
 APPLICATION                                                                                                                   O                                V
      DC-DC converters and power management in portable
  and battery-powered products such as computers, printers,                                                                                           W
                                                                                                           Q                     Q
  PCMCIA cards, cellular and cordless telephones.                                                                  1 2 3

                                                                         N-Channel                         REF.       Millimeter        REF.         Millimeter
                                                                                           D2                       Min.      Max.                Min.      Max.
                                                                                                               A    7.90      8.10       N         0.75     0.95
                                                                                                               B    9.45      9.65       O         0.66     0.86
                                                                                                               C    9.87     10.47       P        13.50    14.50
                                                                                                               D      -      11.50       Q         2.44     3.44
                                                                                                               E    1.06      1.46       R         3.50     3.70
                                                                             G1                                F    2.60      3.00       S         1.15     1.45
                                                                                                               G    6.30      6.70       T         4.30     4.70
                                                                                                               H    8.35      8.75       U           -       2.7
                                                                                                               J       1.60 Typ.         V         1.89     3.09
                                                                                          S3                   K    1.10      1.30       W         0.40     0.60
                                                                                                               L    1.17      1.37       X         2.60     3.60
                                                                                                               M      -       1.50




ABSOLUTE MAXIMUM RATINGS (TA=25
