Image preview - the first page of the document



>> Download sse90n10-14 documenatation <<

Text preview - extract from the document

                                                                                                    SSE90N10-14
                                                                                         90A , 100V , RDS(ON) 16m
                     Elektronische Bauelemente                                     N-Channel Enhancement Mode MOSFET

                                                         RoHS Compliant Product
                                             A suffix of "-C" specifies halogen and lead-free


                                                                                                                              TO-220P
 DESCRIPTION
       These miniature surface mount MOSFETs utilize a                                                                D

    high cell density trench process to provide low RDS(on)                                                           C
    and to ensure minimal power loss and heat dissipation.                                                            B                      R
                                                                                                                                                                  T
                                                                                                                     A
                                                                                                         E
                                                                                                                                                                    S
 FEATURES
        Low RDS(on) provides higher efficiency and                                              G
        extends battery life.                                                                                                       F          I
        Low thermal impedance copper leadframe                                                      H
                                                                                                             J
        TO-220P saves board space.                                                                                               K

        Fast Switch Speed.                                                                                                      L
                                                                                                                                                                        U
        High performance trench technology.                                                              X                       M
                                                                                                                                               P
                                                                                                                                N
 APPLICATION                                                                                                                    O                                   V
      DC-DC converters and power management in portable
  and battery-powered products such as computers, printers,                                             Q                        Q                      W
  PCMCIA cards, cellular and cordless telephones.                                                                 1 2 3

                                                                                                        REF.        Millimeter          REF.          Millimeter
                                                                               N-Channel                          Min.      Max.                   Min.      Max.
                                                                                                         A        7.90      8.10         M            -      1.50
                                                                                                         B        9.45      9.65         N          0.75     0.95
                                                                                       D2                C        9.87     10.47         O          0.66     0.86
                                                                                                         D          -      11.50         P         13.50    14.50
                                                                                                         E        1.06      1.46         Q          2.44     3.44
                                                                                                         F        2.60      3.00         R          3.50     3.70
                                                                          G1                             G        6.30      6.70         S          1.15     1.45
                                                                                                         H        8.35      8.75         T          4.30     4.70
                                                                                                         I        14.7      15.3         U            -       2.7
                                                                                                         J           1.60 Typ.           V          1.89     3.09
                                                                                       S3                K        1.10      1.30         W          0.40     0.60
                                                                                                         L        1.17      1.37         X          2.60     3.60




 ABSOLUTE MAXIMUM RATINGS (TA=25
