Image preview - the first page of the document



>> Download ssf7400 documenatation <<

Text preview - extract from the document

                                                                                                           SSF7400
                                                                                        30V , 1.7A , RDS(ON) 85m
                     Elektronische Bauelemente                                   N-Ch Enhancement Mode Power MOSFET

                                                           RoHS Compliant Product
                                               A suffix of "-C" specifies halogen & lead-free

 DESCRIPTION
       The SSF7400 uses advanced trench technology to                                                                         SOT-323
   provide excellent on-resistance, low gate charge and                                                           A
  operation with gate voltage as low as 2.5V. It can be                                                               L
                                                                                                                  3
  used for a wide variety of applications, including load                                                                                                3

                                                                                                               Top View           C B
  switching, low current inverters and low current DC-DC                                                                                      1

  converters.                                                                                              1              2

                                                                                                   K             E                                 2




 FEATURES                                                                                                                          D
        Lower Gate Charge
                                                                                                   F                          G          H                   J
        Small Package Outline
                                                                                                   REF.             Millimeter           REF.       Millimeter
                                                                                                                  Min.     Max.                   Min.     Max.
                                                                                                       A          1.80     2.20           G        0.100 REF.
 MARKING                                                                                               B          1.80     2.45           H        0.525 REF.
                                                                                                       C          1.15     1.35           J       0.08     0.25
                                                                                                       D          0.80     1.10           K         -        -
        7400                                                                                           E          1.20     1.40           L        0.650 TYP.
                                                                                                       F          0.20     0.40


 PACKAGE INFORMATION
           Package                MPQ             Leader Size
           SOT-323                3K                  7 inch




 ABSOLUTE MAXIMUM RATINGS (TA=25
