Image preview - the first page of the document



>> Download ssg4801 documenatation <<

Text preview - extract from the document

                                                                                                       SSG4801
                                                                                               -5 A, -30 V, RDS(ON) 50 m
                     Elektronische Bauelemente                                         Dual-P Enhancement Mode Power MOSFET

                                                               RoHS Compliant Product
                                                     A suffix of "-C" specifies halogen & lead-free



 DESCRIPTION                                                                                                              SOP-8
          The SSG4801 uses advanced trench technology to
     provide excellent on-resistance, low gate charge and                                                                   B
    operation with gate voltages as low as 2.5V. The device is
    suitable for use as a load switch or in PWM applications.
    It may be used in a common drain arrangement to from a
                                                                                                                                                      L    D
    bidirectional blocking switch.
                                                                                                                                                           M


 FEATURES                                                                                                                   A             C

      Simple Drive Requirement                                                                                                                             N

      Lower On-resistance                                                                                                                 J       K


      Low Gate Charge                                                                                         H      G                            F        E


 MARKING
                                                                                                                   Millimeter                  Millimeter
                                                                                                          REF.                     REF.
                                                                                                                  Min.    Max.                Min.    Max.
                                                                                                            A     5.80    6.20      H         0.35     0.49
        4801SS                                                                                              B     4.80    5.00      J          0.375 REF.
                            = Date Code                                                                     C     3.80    4.00      K              45
