Image preview - the first page of the document



>> Download ssg4953p documenatation <<

Text preview - extract from the document

                                                                                                     SSG4953P
                                                                                          -5.2 A, -30 V, RDS(ON) 52 m
                     Elektronische Bauelemente                                   Dual P-Ch Enhancement Mode Power MOSFET

                                                            RoHS Compliant Product
                                                  A suffix of "-C" specifies halogen & lead-free


 DESCRIPTION                                                                                                             SOP-8
          These miniature surface mount MOSFETs
   utilize high cell density process. Low RDS(on)
   assures minimal power loss and conserves                                                                                B

   energy, making this device ideal for use in
   power management circuitry. Typical applications
   are PWMDC-DC converters, power management                                                                                                         L       D
   in portable and battery-powered products such as                                                                                                          M
   computers, printers, battery charger, telecommunication
   power system, and telephones power system.                                                                              A             C
                                                                                                                                                             N

                                                                                                                                         J       K


 FEATURES                                                                                                    H       G                           F           E
      Low RDS(on) provides higher efficiency and extends
       battery life.                                                                                        REF.    Millimeter
                                                                                                                   Min.    Max.
                                                                                                                                  REF.        Millimeter
                                                                                                                                             Min.    Max.
      Miniature SOP-8 surface mount package saves                                                            A     5.80    6.20    H         0.35     0.49
                                                                                                             B     4.80    5.00    J          0.375 REF.
      board space.                                                                                           C     3.80    4.00    K              45
