                                                                                                SSP7150N
                                                                                          3.6A, 150V, RDS(ON) 255 m
                     Elektronische Bauelemente                                         N-Channel Enhancement MOSFET

                                                         RoHS Compliant Product
                                               A suffix of "-C" specifies halogen & lead-free



 FEATURES                                                                                                      SOP-8PP
        Low RDS(on) trench technology.
        Low thermal impedance.
        Fast switching speed.


 APPLICATIONS
        White LED boost converters.
        Automotive Systems.
        Industrial DC/DC Conversion Circuits.



 PACKAGE INFORMATION
            Package              MPQ             Leader Size
           SOP-8PP                3K                13 inch




                                                                                                     REF.     Millimeter     REF.     Millimeter
                                                                                                             Min.   Max.             Min.   Max.
                                                                                                      A      0.85    1.00             0
