Image preview - the first page of the document



>> Download ssp7431p documenatation <<

Text preview - extract from the document

                                                                                                SSP7431P
                                                                                           -17A, -30V, RDS(ON) 13 m
                     Elektronische Bauelemente                                         P-Channel Enhancement MOSFET

                                                         RoHS Compliant Product
                                               A suffix of "-C" specifies halogen & lead-free



 DESCRIPTION                                                                                                       SOP-8PP
          These miniature surface mount MOSFETs utilize
    a high cell density trench process to provide low RDS(on)
    and to ensure minimal power loss and heat dissipation.


 FEATURES
         Low RDS(on) provides higher efficiency and extends
         battery life.
         Low thermal impedance copper leadframe SOP-8PP
         saves board space.
         Fast switching speed.
         High performance trench technology.


APPLICATION
        DC-DC converters and power management in
   portable and battery-powered products such as
   computers, printers, PCMCIA cards, cellular and
   cordless telephones.

 PACKAGE INFORMATION
             Package                MPQ             Leader Size
                                                                                                         REF.     Millimeter     REF.     Millimeter
            SOP-8PP                 3K                  13 inch                                                  Min.   Max.             Min.   Max.
                                                                                                          A      0.85    1.00             0
