Image preview - the first page of the document



>> Download ssp7438n documenatation <<

Text preview - extract from the document

                                                                                                     SSP7438N
                                                                                              22 A, 30 V, RDS(ON) 7.5 m
                     Elektronische Bauelemente                                            N-Channel Enhancement MOSFET

                                                            RoHS Compliant Product
                                                  A suffix of "-C" specifies halogen & lead-free



 DESCRIPTION                                                                                                        SOP-8PP
      These miniature surface mount MOSFETs utilize a high cell
  density trench process to provide low RDS(on) and to ensure
  minimal power loss and heat dissipation.


 FEATURES
        Low RDS(on) provides higher efficiency and extends battery life.
        Low thermal impedance copper leadframe SOP-8PP saves board
        space.
        Fast switching speed.
        High performance trench technology.


 APPLICATION
       DC-DC converters and power management in
 portable and battery-powered products such as computers,
 printers, PCMCIA cards, cellular and cordless telephones

 PACKAGE INFORMATION

                                                                                                                 Millimeter               Millimeter
              Package                 MPQ               Leader Size                          Drain      REF.
                                                                                                                Min.   Max.
                                                                                                                                REF.
                                                                                                                                         Min.   Max.
                                                                                                         A      0.85    1.00              0
