                                                                                                  SSPS7321P
                                                                                           -13A , -20V , RDS(ON) 14 m
                     Elektronische Bauelemente                                      P-Ch Enhancement Mode Power MOSFET

                                                          RoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free


 DESCRIPTION                                                                                                         DFN3x3-8PP
           These miniature surface mount MOSFETs
                                                                                                                             B
   utilize a high cell density trench process to provide
   low RDS(on) and to ensure minimal power loss and
   heat dissipation.                                                                                             D


                                                                                                                                                       C
 FEATURES
         Low RDS(on) provides higher efficiency and                                                                            e       E
         extends battery life
         Low thermal impedance copper leadframe
                                                                                                                                               A
         DFN3x3-8PP saves board space
                                                                                                                      d                        b
         Fast switching speed
         High performance trench technology
                                                                                                                                                   g

 APPLICATION
          DC-DC converters and power management in portable
                                                                                                                                                           F
   and battery-powered products such as computers,
   printers, PCMCIA cards, cellular and cordless telephones.
                                                                                                                                   G
                                                                                    Top View
                                                                                                                  Millimeter                    Millimeter
 PACKAGE INFORMATION                                                                                      REF.
                                                                                                                 Min.    Max.
                                                                                                                                   REF.
                                                                                                                                               Min.   Max.
                                                                                                           A     0.70    0.90                   0
