Image preview - the first page of the document



>> Download ssps7330n documenatation <<

Text preview - extract from the document

                                                                                                  SSPS7330N
                                                                                           11 A , 30 V, RDS(ON) 22 m
                     Elektronische Bauelemente                                      N-Ch Enhancement Mode Power MOSFET

                                                          RoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free


 DESCRIPTION                                                                                                        DFN3x3-8PP
           These miniature surface mount MOSFETs
                                                                                                                             B
   utilize a high cell density trench process to provide
   low RDS(on) and to ensure minimal power loss and
   heat dissipation. Typical applications are                                                                   D


                                                                                                                                                       C
 FEATURES

         Low RDS(on) provides higher efficiency and                                                                           e        E
         extends battery life
         Low thermal impedance copper leadframe
                                                                                                                                               A
         DFN3x3-8PP saves board space
                                                                                                                      d                        b
         Fast switching speed
         High performance trench technology
                                                                                                                                                   g

 APPLICATION
          DC-DC converters and power management in                                                                                                         F
   portable and battery-powered products such as computers,
   printers, PCMCIA cards, cellular and cordless telephones.
                                                                                                                                   G


 PACKAGE INFORMATION                                                               Top View
                                                                                                                     Millimeter                 Millimeter
                                                                                                          REF.                         REF.
                                                                                                                    Min.    Max.               Min.   Max.
            Package                   MPQ          Leader Size                                              A       0.70    0.90                0
