Image preview - the first page of the document
>> Download ssps7333p documenatation <<
Text preview - extract from the document
SSPS7333P
-10.9 A , -30 V , RDS(ON) 20 m
Elektronische Bauelemente P-Ch Enhancement Mode Power MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
DESCRIPTION DFN3x3-8PP
These miniature surface mount MOSFETs
utilize a high cell density trench process to provide B
low RDS(on) and to ensure minimal power loss and
heat dissipation.
D
C
FEATURES
Low RDS(on) provides higher efficiency and
extends battery life e E
Low thermal impedance copper leadframe
DFN3x3-8PP saves board space A
Fast switching speed d b
High performance trench technology
g
APPLICATION
DC-DC converters and power management in
portable and battery-powered products such as F
computers, printers, PCMCIA cards, cellular and
cordless telephones.
G
PACKAGE INFORMATION Top View
Package MPQ Leader Size REF.
Millimeter
REF.
Millimeter
Min. Max. Min. Max.
A 0.70 0.90 0◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
