Image preview - the first page of the document



>> Download ssps924ne documenatation <<

Text preview - extract from the document

                                                                                                  SSPS924NE
                                                                                           9.2A , 20V , RDS(ON) 12 m
                     Elektronische Bauelemente                                      N-Ch Enhancement Mode Power MOSFET

                                                          RoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free


 DESCRIPTION                                                                                                           DFN3x3-8PP
         These miniature surface mount MOSFETs                                                                                B
   utilize a high cell density trench process to provide
   low RDS(on) and to ensure minimal power loss and
   heat dissipation.                                                                                            D


                                                                                                                                                       C
 FEATURES
        Low RDS(on) provides higher efficiency and                                                                             e       E
        extends battery life
        Low thermal impedance copper leadframe
                                                                                                                                              A
        DFN3x3-8PP saves board space
        Fast switching speed                                                                                           d                       b
        High performance trench technology
                                                                                                                                                   g
 APPLICATION
        DC-DC converters and power management in portable
   and battery-powered products such as computers,                                                                                                         F
   printers, PCMCIA cards, cellular and cordless telephones.
                                                                                                                                   G

 PACKAGE INFORMATION                                                                                     REF.
                                                                                                                     Millimeter
                                                                                                                    Min.    Max.
                                                                                                                                   REF.
                                                                                                                                               Millimeter
                                                                                                                                              Min.   Max.
                                                                                                          A         0.70    0.90               0
