Image preview - the first page of the document
>> Download ssq6n60 documenatation <<
Text preview - extract from the document
SSQ6N60
2.6A, 600V, RDS(ON) 1500m
Elektronische Bauelemente N-Ch Enhancement Mode Power MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen free
TO-220P
D
FEATURES C
Low RDS(on) Technology.
B
Low thermal impedance. R
T
Fast switching speed. E A
S
G
APPLICATIONS F I
Electronic ballast. H
Electronic transformer J K
Switch mode power supply. L
U
X M
P
N
O V
Q Q W
1 2 3
Dimensions in millimeters
Drain REF.
Millimeter
REF.
Millimeter
Min. Max. Min. Max.
A 7.90 8.10 N 0.75 0.95
B 9.45 9.65 O 0.66 0.86
C 9.87 10.47 P 13.50 14.50
D - 11.50 Q 2.44 3.44
Gate E 1.06 1.46 R 3.50 3.70
F 2.60 3.00 S 1.15 1.45
G 6.30 6.70 T 4.30 4.70
H 8.35 8.75 U - 2.7
J 1.60 Typ. V 1.89 3.09
K 1.10 1.30 W 0.40 0.60
Source L 1.17 1.37 X 2.60 3.60
M - 1.50
ABSOLUTE MAXIMUM RATINGS (TA = 25◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
