                                                                                               SSRF30N20-400
                                                                                            23A, 200V, RDS(ON) 400m
                     Elektronische Bauelemente                                       N-Ch Enhancement Mode Power MOSFET

                                                           RoHS Compliant Product
                                                     A suffix of "-C" specifies halogen free
 DESCRIPTION
     These miniature surface mount MOSFETs utilize a high cell density trench                                                ITO-220
     process to provide Low RDS(on) and to ensure minimal power loss and heat
     dissipation. Typical applications are DC-DC converters and power management                                    B                  N
     in portable and battery-powered products such as computers, printers, PCMCIA
                                                                                                                                                        D
     cards, cellular and cordless telephones.                                                                                                           E

                                                                                                                              M        A
 FEATURES
           Low RDS(on) provides higher efficiency and extends battery life.
           Low thermal impedance copper leadframe ITO-220 saves board
           space.                                                                                         H                   J        C
           Fast switching speed.
           High performance trench technology.                                                                                K                         G
                                                                                                          L                   L                         F
 PRODUCT SUMMARY                                                                                                     Dimensions in millimeters

                             SSRF30N20-400
         VDS(V)              RDS(on) (m              ID(A)                                                            Millimeter                    Millimeter
                                                                                                          REF.                          REF.
                            400@VGS= 10V                  1
                                                                                                                    Min.     Max.                 Min.     Max.
           200                                       23                                                     A       15.00    15.60       H        3.00     3.80
                            450@VGS= 4.5V                                                                   B
                                                                                                            C
                                                                                                                    9.50     10.50
                                                                                                                      13.00 Min
                                                                                                                                         J
                                                                                                                                         K
                                                                                                                                                  0.90
                                                                                                                                                  0.50
                                                                                                                                                           1.50
                                                                                                                                                           0.90
                                                                                                            D       4.30     4.70        L        2.34     2.74
                                                                                                            E       2.50     3.10        M        2.50     2.90
                                                                                                            F       2.40     2.80        N         3.1     3.4
                                                                                                            G       0.30     0.70



                                                                                                                                     Drain



                                                                                                                  Gate




                                                                                                                                   Source
