                                                                                                  SSRF90N06
                                                                                    N-Ch Enhancement Mode Power MOSFET
                     Elektronische Bauelemente                                             87A, 60V, RDS(ON) 26.5m

                                                          RoHS Compliant Product
                                                    A suffix of "-C" specifies halogen free
 DESCRIPTION
     These miniature surface mount MOSFETs utilize a high cell density trench                                                  ITO-220
     process to provide Low RDS(on) and to ensure minimal power loss and heat
     dissipation. Typical applications are DC-DC converters and power management                                      B                  N
     in portable and battery-powered products such as computers, printers, PCMCIA
                                                                                                                                                          D
     cards, cellular and cordless telephones.                                                                                                             E

                                                                                                                                M        A
 FEATURES
           Low RDS(on) provides higher efficiency and extends battery life.
           Low thermal impedance copper leadframe ITO-220 saves board
           space.                                                                                           H                   J        C
           Fast switching speed.
           High performance trench technology.                                                                                  K                         G
                                                                                                            L                   L                         F
 PRODUCT SUMMARY                                                                                                       Dimensions in millimeters

                        PRODUCT SUMMARY
         VDS(V)           RDS(on) m(                ID(A)
                                                                                                            REF.         Millimeter       REF.        Millimeter
                         26.5@VGS= 10V                    a                               Drain
                                                                                                                      Min.      Max.                Min.     Max.
            60                                       87                                                       A       15.00     15.60      H        3.00     3.80
                         32.5@VGS= 4.5V                                                                       B
                                                                                                              C
                                                                                                                       9.50     10.50
                                                                                                                         13.00 Min
                                                                                                                                           J
                                                                                                                                           K
                                                                                                                                                    0.90
                                                                                                                                                    0.50
                                                                                                                                                             1.50
                                                                                                                                                             0.90
                                                                                                              D        4.30      4.70      L        2.34     2.74
                                                                                                              E        2.50      3.10      M        2.50     2.90
                                                                            Gate                              F        2.40      2.80      N         3.1     3.4
                                                                                                              G        0.30      0.70




                                                                                         Source




 ABSOLUTE MAXIMUM RATINGS (TA = 25
