>> Download stt3402n documenatation <<

Text preview - extract from the document

                                                                                                      STT3402N
                                                                                           6.3 A, 30 V, RDS(ON) 27 m
                     Elektronische Bauelemente                                       N-Channel Enhancement Mode Mos.FET

                                                           RoHS Compliant Product
                                               A suffix of "-C" specifies halogen and lead-free
 DESCRIPTION                                                                                                                   TSOP-6
     These miniature surface mount MOSFETs utilize High Cell Density                                                  A
 process. Low RDS(on) assures minimal power loss and conserves energy,                                                E
                                                                                                                                L
 making this device ideal for use in power management circuitry. Typical                                        6     5    4

 applications are power switch, power management in portable and
 battery-powered products such as computers, printers, PCMCIA cards,
                                                                                                                                B
 cellular and cordless telephones.

 TYPICAL APPLICATIONS                                                                                     F
                                                                                                                1     2    3
                                                                                                                                                 C            H
             Low RDS(on) Provides Higher Efficiency and                                                 DG                           K                        J
             Extends Battery Life.
             Low Gate Charge.
             Fast Switch.
             Miniature TSOP-6 Surface Mount Package                                                           REF.
                                                                                                                       Millimeter
                                                                                                                                     REF.
                                                                                                                                              Millimeter
                                                                                                                      Min.   Max.            Min.   Max.
             Saves Board Space.                                                                                A      2.70    3.10       G    0     0.10
                                                                                                               B      2.60    3.00       H    0.60 REF.
                                                                                                               C      1.40    1.80       J    0.12 REF.
                                                                                                               D       1.10 MAX.         K    0
