>> Download stt3962n documenatation <<

Text preview - extract from the document

                                                                                                      STT3962N
                                                                                     N-Channel Enhancement Mode Mos.FET
                     Elektronische Bauelemente                                            2.3 A, 60 V, RDS(ON) 0.153

                                                          RoHS Compliant Product
                                              A suffix of "-C" specifies halogen and lead-free
 DESCRIPTION                                                                                                                   TSOP-6
      These miniature surface mount MOSFETs utilize High Cell Density                                                 A
      process. Low RDS(on) assures minimal power loss and conserves                                                   E
                                                                                                                                L
      energy, making this device ideal for use in power management                                              6     5    4

      circuitry. Typical applications are DC-DC converters, power
      management in portable and battery-powered products such as
                                                                                                                                B
      computers, printers, PCMCIA cards, cellular and cordless telephones.


 FEATURES                                                                                                 F
                                                                                                                1     2    3
                                                                                                                                                 C            H
             Low RDS(on) provides higher efficiency and extends battery life.                           DG                           K                        J
             Miniature TSOP-6 surface mount package saves board space.

 PRODUCT SUMMARY
                                                                                                                       Millimeter             Millimeter
                                                                                                              REF.                   REF.
         PRODUCT SUMMARY                                                                                       A
                                                                                                                      Min.
                                                                                                                      2.70
                                                                                                                             Max.
                                                                                                                              3.10       G
                                                                                                                                             Min.
                                                                                                                                              0
                                                                                                                                                    Max.
                                                                                                                                                    0.10
         VDS(V)                RDS(on) (             ID(A)                                                     B
                                                                                                               C
                                                                                                                      2.60
                                                                                                                      1.40
                                                                                                                              3.00
                                                                                                                              1.80
                                                                                                                                         H
                                                                                                                                         J
                                                                                                                                              0.60 REF.
                                                                                                                                              0.12 REF.
                            0.153@VGS= 10V            2.3                                                      D       1.10 MAX.         K    0
