Image preview - the first page of the document



>> Download stt3981 documenatation <<

Text preview - extract from the document

                                                                                                  STT3981
                                                                                     -1.6 A, -20 V, RDS(ON) 180 m
                 Elektronische Bauelemente                                       P-Channel Enhancement Mode Mos.FET

                                                    RoHS Compliant Product
                                        A suffix of "-C" specifies halogen and lead-free

DESCRIPTION
     The STT3981 utilized advance processing techniques to achieve the lowest possible on-resistance, extremely
     efficient and cost-effectiveness device. The STT3981 is universally used for all commercial-industrial applications.


FEATURES
     Low On-Resistance
     Low Gate Charge


PACKAGE DIMENSIONS




                                                                                      Millimeter               Millimeter
                                                                           REF.                        REF.
                                                                                     Min.    Max.             Min.     Max.
                                                                            A           1.10 Max        L         0.45 Ref
                                                                            A1        0        0.10    L1         0.60 Ref
                                                                            A2       0.70      1.00            0
