Image preview - the first page of the document
>> Download pzt13003 documenatation <<Text preview - extract from the document PZT13003
1.5A , 700V
Elektronische Bauelemente NPN Silicon Medium Power Transistor
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
FEATURES SOT-223
For AF driver and output stages
Power switching applications A
M
CLASSIFICATION OF hFE 4
Top View CB
Product-Rank PZT13003-A PZT13003-B PZT13003-C 1
2
Range 8~20 15~30 25~40 K L 3
E
PACKAGE INFORMATION D
F G H J
Package MPQ Leader Size
Millimeter Millimeter
SOT-223 2.5K 13 inch REF.
Min. Max.
REF.
Min. Max.
A 6.20 6.70 G - 0.10
B 6.70 7.30 H - -
C 3.30 3.70 J 0.25 0.35
D 1.42 1.90 K - -
E 4.50 4.70 L 2.30 REF.
F 0.60 0.82 M 2.90 3.10
ABSOLUTE MAXIMUM RATINGS (TA=25
