Image preview - the first page of the document



>> Download pzt2907a documenatation <<

Text preview - extract from the document

                                                                                                              PZT2907A
                                                                                                        PNP Silicon
                     Elektronische Bauelemente                                           Silicon Planar Medium Power Transistor

                                                          RoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free
                                                                                                                              SOT-223
 DESCRIPTION
     The PZT2907A is designed for general purpose amplifier
     and high-speed switching, medium power switching applications.




 MARKING
                                                                   Collector


         2907A
                             = Date code             Base
                                                                                                                    Millimeter                        Millimeter
                                                                                                      REF.                               REF.
                                                                                                                  Min.      Max.                    Min.      Max.
         B     C     E                                                                                 A          6.30      6.70          G         0.02      0.10
                                                                       Emitter
                                                                                                       B          6.70      7.30          H         1.50      2.00
                                                                                                       C          3.30      3.70          J         0.25      0.35
                                                                                                       D          1.42      1.90          K         0.85      1.05
                                                                                                       E            4.60 REF.             L           2.30 REF.
                                                                                                       F          0.60      0.80          M         2.90      3.10
                                                                                                       I          0.02      0.10          N            13 TYP.
                                                                                                       O           0
