                                                                                                                   UMX1N
                                                                                          Dual NPN General Purpose Transistors
                     Elektronische Bauelemente

                                                                 RoHS Compliant Product
                                                       A suffix of "-C" specifies halogen & lead-free



 FEATURES
            Two 2SC2412K chips in a package.                                                                                       SOT-363
            Mounting possible with SOT-363 automatic
            mounting machines.                                                                                         A
            Transistor elements are independent, eliminating                                                           E
            interference.                                                                                      6       5       4
                                                                                                                                     L
            Mounting cost and area can be cut in half.

                                                                                                                                     B

 EQUIVALENT CIRCUIT
                                                                                                               1       2       3
                                                                                                         F                                              C               H
                           (3)   (2)    (1)
                                                                                                    DG                                    K                             J
                                       Tr1
                     Tr2


                           (4)   (5)    (6)
                                                                                                                          Millimeter                    Millimeter
                                                                                                             REF.                             REF.
                                                                                                                        Min.     Max.                 Min.     Max.
                                                                                                              A         2.00     2.20          G       0.100 REF.
                                                                                                              B         2.15     2.45          H       0.525 REF.
                                                                                                              C         1.15     1.35          J      0.08     0.15
 MARKINGX1                                                                                                    D         0.90     1.10          K            8
