Image preview - the first page of the document
2n5404_2n5405_2n5406_2n5407


>> Download 2n5404_2n5405_2n5406_2n5407 documenatation <<

Text preview - extract from the document
                                                                                                                       2N5404
                                                                                                                       2N5405
                                                                                                                       2N5406
                                                                                                                       2N5407

MECHANICAL DATA                                                                           SMALL SIGNAL
Dimensions in mm
                                                8.89 (0.35)
                                                                                         PNP TRANSISTORS
                                                9.40 (0.37)

                                                7.75 (0.305)
                                                8.51 (0.335)
                                                                                              IN TO-5
          4.19 (0.165)
          4.95 (0.195)




                             0.89 max.
                38.1       (0.035)
              (1.500)
                min.        7.75 (0.305)
                                                                                     APPLICATIONS
                            8.51 (0.335)
                                dia.


                                                                                     Small signal PNP transistors for relay
                                                5.08 (0.200)
                                                    typ.
                                                                                     switching resistor logic circuits and
                                                                                     general purpose applications.
                                                                       2.54
                                                     2               (0.100)
                                                1             3
                  0.66 (0.026)
                  1.14 (0.045)

                  0.71 (0.028)
                  0.86 (0.034)




                                           45




                                           TO-5
  Pin1 - Emitter                   Pin2 - Base                    Pin3 - Collector



ABSOLUTE MAXIMUM RATINGS (Tcase = 25
