>> Download 2n6465 documenatation <<Text preview - extract from the document
Dimensions in mm (inches).
Bipolar NPN Device in a
Hermetically sealed TO66
3.68 8.64 (0.340) Metal Package.
(0.145) rad. 3.61 (0.142)
Bipolar NPN Device.
VCEO = 110V
IC = 4A
All Semelab hermetically sealed products
can be processed in accordance with the
requirements of BS, CECC and JAN,
1.27 (0.050) JANTX, JANTXV and JANS specifications
4.83 (0.190) 1.91 (0.750)
