Image preview - the first page of the document



>> Download 2n6786 documenatation <<

Text preview - extract from the document

                                                                                                                                          2N6786



  Dimensions in mm (inches).
                                                  8.64 (0.34)
                                                                                                    N-Channel MOSFET
                                                  9.40 (0.37)

                                                  8.01 (0.315)
                                                  9.01 (0.355)
                                                                                                            in a
                                                                                                  Hermetically sealed TO39
             4.06 (0.16)
             4.57 (0.18)                                                                              Metal Package.
                                0.89 max.
                  12.70       (0.035)
                 (0.500)
                   min.        0.41 (0.016)
                               0.53 (0.021)
                                   dia.

                                                                                                     N-Channel MOSFET.
                                                  5.08 (0.200)
                                                      typ.
                                                                                                     VDSS = 400V

                                                       2
                                                                    2.54
                                                                  (0.100)
                                                                                                     ID = 1.25A
                                                  1          3
                     0.74 (0.029)
                     1.14 (0.045)                                                                    RDS(ON) = 3.6
                     0.71 (0.028)
                     0.53 (0.021)


                                                                                                     All Semelab hermetically sealed products can be
                                                                                                     processed in accordance with the requirements
                                            45
