Image preview - the first page of the document



>> Download 2n7008 documenatation <<

Text preview - extract from the document

                                                                                                                                         2N7008

                                                   N-Channel Enhancement-Mode
                                                   Vertical DMOS FETs

Features                                                                                  General Description
       Free from secondary breakdown                                                      The Supertex 2N7008 is an enhancement-mode (normally-
       Low power drive requirement                                                        off) transistor that utilizes a vertical DMOS structure
                                                                                          and Supertex's well-proven silicon-gate manufacturing
       Ease of paralleling
                                                                                          process. This combination produces a device with the
       Low CISS and fast switching speeds                                                 power handling capabilities of bipolar transistors, and the
       Excellent thermal stability                                                        high input impedance and positive temperature coefficient
       Integral source-drain diode                                                        inherent in MOS devices. Characteristic of all MOS
       High input impedance and high gain                                                 structures, this device is free from thermal runaway and
       Complementary N- and P-Channel devices                                             thermally-induced secondary breakdown.

Applications                                                                              Supertex's vertical DMOS FETs are ideally suited to a
                                                                                          wide range of switching and amplifying applications where
       Motor controls                                                                     very low threshold voltage, high breakdown voltage, high
       Converters                                                                         input impedance, low input capacitance, and fast switching
       Amplifiers                                                                         speeds are desired.
       Switches
       Power supply circuits
       Drivers (relays, hammers, solenoids, lamps,
       memories, displays, bipolar transistors, etc.)




Ordering Information
                                                                BVDSS/BVDGS               RDS(ON)             ID(ON)
         Device                Package Option                                              (max)              (min)
                                                                        (V)                 ()                (mA)

       2N7008-G                        TO-92                            60                  7.5               500
-G indicates package is RoHS compliant (`Green')



Absolute Maximum Ratings                                                                  Pin Configuration
    Parameter                                                                 Value
    Drain-to-source voltage                                                   BVDSS
                                                                                                                               SOURCE

    Drain-to-gate voltage                                                     BVDGS                                    DRAIN

    Gate-to-source voltage
