Image preview - the first page of the document



>> Download lnd150 documenatation <<

Text preview - extract from the document

                                                                                                                                                        LND150
                                                           N-Channel Depletion-Mode
                                                           DMOS FET
Features                                                                                   General Description
        Free from secondary breakdown                                                      The LND150 is a high voltage N-channel depletion mode
        Low power drive requirement                                                        (normally-on) transistor utilizing Supertex's lateral DMOS
        Ease of paralleling                                                                technology. The gate is ESD protected.
        Excellent thermal stability
        Integral source-drain diode                                                        The LND150 is ideal for high voltage applications in the
        High input impedance and low CISS                                                  areas of normally-on switches, precision constant current
        ESD gate protection                                                                sources, voltage ramp generation and amplification.

Applications
       Solid state relays
       Normally-on switches
       Converters
       Power supply circuits
       Constant current sources
       Input protection circuits

Ordering Information
                                                    Package Options                                                                     RDS(ON)                  IDSS
                                                                                                                 BVDSX/BVDGX
     Device                                                                                                                                 (max)               (min)
                   TO-236AB (SOT-23)                        TO-92                TO-243AA (SOT-89)                    (V)
                                                                                                                                             (K)                (mA)
    LND150              LND150K1-G                     LND150N3-G                      LND150N8-G                    500                    1.0                  1.0
-G indicates package is RoHS compliant (`Green')


                                                                                          Pin Configurations


                                                                                                                                    DRAIN


Absolute Maximum Ratings                                                                                                   SOURCE

    Parameter                                                               Value
                                                                                                                                        GATE
    Drain-to-source                                                            BVDSX
                                                                                                                           TO-92 (N3)
    Drain-to-gate                                                           BVDGX
    Gate-to-source
