Image preview - the first page of the document



>> Download tn2106 documenatation <<

Text preview - extract from the document

                                                                                                                                                         TN2106

                                                      N-Channel Enhancement-Mode
                                                      Vertical DMOS FET
Features                                                                                   General Description
        Free from secondary breakdown                                                      This low threshold, enhancement-mode (normally-off)
        Low power drive requirement                                                        transistor utilizes a vertical DMOS structure and Supertex's
        Ease of paralleling                                                                well-proven, silicon-gate manufacturing process. This
        Low CISS and fast switching speeds                                                 combination produces a device with the power handling
        Excellent thermal stability                                                        capabilities of bipolar transistors and the high input
        Integral source-drain diode                                                        impedance and positive temperature coefficient inherent
        High input impedance and high gain                                                 in MOS devices. Characteristic of all MOS structures, this
        Complementary N- and P-channel devices                                             device is free from thermal runaway and thermally-induced
                                                                                           secondary breakdown.
Applications                                                                               Supertex's vertical DMOS FETs are ideally suited to a
       Logic level interfaces - ideal for TTL and CMOS                                     wide range of switching and amplifying applications where
       Solid state relays                                                                  very low threshold voltage, high breakdown voltage, high
       Battery operated systems                                                            input impedance, low input capacitance, and fast switching
       Photo-voltaic drives                                                                speeds are desired.
       Analog switches
       General purpose line drivers
       Telecom switches




Ordering Information
                                                  Package Option                                                                       RDS(ON)             VGS(th)
                                                                                                     BVDSS/BVDGS
       Device                                                                                                                           (max)              (max)
                               TO-236AB (SOT-23)                                 TO-92                       (V)
                                                                                                                                         ()                 (V)
       TN2106                        TN2106K1-G                             TN2106N3-G                       60                          2.5                2.0
-G indicates package is RoHS compliant (`Green')

                                                                                          Pin Configurations
                                                                                                  DRAIN

                                                                                                                                                         SOURCE

                                                                                                                   SOURCE                        DRAIN
                                                                                                          GATE


Absolute Maximum Ratings                                                                                                                                   GATE

    Parameter                                                               Value          TO-236AB (SOT-23) (K1)                                TO-92 (N3)
    Drain-to-source                                                         BVDSS
    Drain-to-gate                                                           BVDGS         Product Marking
    Gate-to-source
