Image preview - the first page of the document
>> Download tc2320pss documenatation <<
Text preview - extract from the document
Product TC2320TG
Summary N- and P-Channel Enhancement-Mode Dual MOSFET
Sheet TC2320TG
+100V
12V
Logic Input
Applications
10nF
- Medical ultrasound
transmitters
- High voltage pulsers 12V Piezo
- Amplifiers Analog Switch Electric
Transducer
- Buffers Logic Input
10nF
- Piezoelectric transducer
drivers -100V
- General purpose line drivers Typical Application Circuit for Pulser
- Logic level interfaces
Product Overview:
The TC2320TG is a complementary high-speed, high voltage N- and P-channel
MOSFET in a single SO-8 package. The TC2320TG offers 200V breakdown volt-
age, 2.0A output peak current, and low input capacitance. The 2.0A output current
capability will minimize rise and fall times. The low input capacitance will minimize
propagation delay times and also rise and fall times. The MOSFETs are electrically
isolated from each other by a custom lead frame that encapsulates two independent
dice to minimize crosstalk. These combined features are ideally suited for high-
speed high voltage pulsers. Typical applications would be for medical ultrasound
transmitters and class D amplifiers.
Features: Benefits:
200V Drain-to-Source Breakdown Voltage Common voltage range for medical ultrasound
2.0A Id(on) Enough current to drive transducers with rise and fall
times of 20ns for proper imaging
Low Input Capacitance Eases gate drive requirement to meet desired output
speed
SO-8 package Simplifies PCB assembly
4/25/02
TC2320TG
N- and P-Channel Enhancement-Mode Dual MOSFET
Typical Performance
Device BVDSS/BVDGS R DS(ON)
N-Channel P-Channel N-Channel P-Channel
TC2320TG +200V -200V 7.0 12
Ordering Information / Availability
Part Number Datasheet Samples Lead Time
TC2320TG TC2320 TC2320TG 4 - 5 weeks ARO
Now Now
Product Contact
If you have any questions regarding the TC2320TG or would like to receive samples,
contact Supertex Applications at:
Telephone: (800) 222-9883
Fax: (408) 222-4895
Email: [email protected]
Web: www.supertex.com
Supertex Sales: Contact your Supertex Area Sales Office
1235 Bordeaux Drive, Sunnyvale, CA 94089
